Medical devices serve as important indicators of the level of medical science and technology, and SDI signal slip rings are widely used as essential core components in the production of high-tech products such as medical instruments and medical equipment. Nowadays, slip rings have become indispensable components of many medical devices.

As a pioneer among international slip ring manufacturers, JINPAT has the ability to manufacture various categories of SDI signal slip rings in large quantities, including HD-SDI, 3G-SDI, 6G-SDI and 12G-SDI, as well as their integrated products. Equipment used in narrow-space detection, machine vision and other fields usually integrate high-definition optical sensor systems, and in most cases, the high-definition SDI video signals generated by these systems are transmitted via coaxial cables. When these optical systems are integrated into gimbals that can rotate 360°, it becomes necessary to install a slip ring assembly embedded in the high-definition video signal to maintain the SDI signal transmission path.

Devices such as surgical robots, high-speed intravascular ultrasound scanners, magnetic resonance imaging, ophthalmological examination and treatment instruments are all vital equipment in the medical field. As various highly advanced surgical robots with complex functional capabilities gradually develop, slip rings specific to this field will also be developed comprehensively.

SDI high definition video signal slip rings, which are important components of robotic arms, are present in the visual systems of these medical robots. Robotic arms can rotate 360 ​​degrees freely without limitation and require continuous power supply, which makes it necessary to have a component that can rotate 360 ​​degrees freely and continuously to ensure their proper operation, and the SDI signal slip ring precisely meets this requirement. JINPAT has extensive experience in developing multi-signal integrated slip rings, which can transmit various special signals inside a compact slip ring. The slip rings developed by JINPAT for the medical industry are mainly small-sized products, and most of them are in the category of LPC capsule slip rings with 30 channels or less, LPM full-series slip rings, and some LPMS slip rings. For example, LPMS-12 UHD 01-08 S is an extremely compact 3G-SDI signal embedded slip ring with an outer diameter of 6.5mm and a length of 17.4mm. This slip ring is probably the smallest 3G-SDI signal embedded slip ring available on the global market. Of course, if customers have special requirements, JINPAT can also develop a smaller SDI signal slip ring based on LPMS-08D with a diameter of 5.5mm. However, in most cases, medical SDI signal slip rings are developed based on LPM or LPC, because many medical instruments do not require extremely compact slip rings, and the size of the slip ring is not a critical factor under normal circumstances.
