The LPC-1C3602 is a hybrid high frequency and electrical slip ring with an outside diameter of 24.8 mm and a length of 68.5 mm. This high-frequency coaxial rotating contact can be with or without an elbow, providing greater flexibility for installation on a variety of platforms. The slip ring features high precision design, low contact resistance, low torque, long life and reliable performance. This slip ring is particularly suitable for small rotary systems that transmit weak control signals. It is compatible with data bus protocol and SDI signals.

Features:
Up to 4 loops (model with more loops is customizable)
Frequency up to 50 GHz
Compact structure with low interference
Transmission of multiple signals simultaneously
Ultra-low insertion loss and transmission fluctuations
Long service life and no maintenance required

Applications:
Radar antenna, military system devices
High definition video surveillance network system
Satellite communication system
Medical instrument for treatment
Air traffic control and missile defense system
