LPC-1C1202 is a hybrid slip ring designed based on a high frequency slip ring and a capsule slip ring. It has an outer diameter of 22 mm and a length of 39.8 mm. The slip ring model can be designed with or without an elbow. The slip ring utilizes advanced military-grade techniques to process the surface of the block. LPC-1C1202 is characterized by high precision design, low contact resistance, low torque, long life and reliable performance. This slip ring is particularly suitable for small rotor systems that transmit weak control signals. It is compatible with data bus protocol and SDI signals.

Options available.
◎ Number of channels
◎ Frequency range of the high frequency signal
◎ Rated voltage and rated current
◎ Support for mixed transmission of HF signals and current or other signals

Typical applications.
◎ Radar antennas, military system equipment
◎ High definition video surveillance network systems
◎ Satellite communication systems
◎ Medical engineering equipment
◎ Air traffic control, missile defense systems
