Description:

This device can be used in any electromechanical system requiring unrestrained, continuous rotation in the transfer of power or data from a fixed to a rotating structure.

It is also referred to as a rotating electrical interface, switch, manifold, hinge, or electrical rotating joint. It can improve electromechanical capabilities, simplify system design, and eliminate possible rotational damage. It is the key apparatus of various precision rotary work tables, electrical test instruments, manufacturing and process control instruments.

The LPS-15 separate slip ring is a standard off-the-shelf device that utilizes gold contacts on the rotating interface. Color-coded wires are used on the stator and rotor to simplify electrical connections.

By utilizing a 90° V-groove in the design of each ring, the LPS-15 provides smoother running, lower torque and less electrical noise than competitive slip rings.

Features

◆ 15 chain models

◆ Speed up to 100 rpm in continuous mode

◆ Gold-Gold contacts

◆ Standard wire length of 250 mm

◆ Compatible with data bus protocols

◆ Sealed units available

◆ Flexible, color-coded, silver-plated, ear wires

◆ Precision ball bearings meet or exceed life requirements for most commercial applications

Benefits

◆ Low torque minimizes system torque budget

◆ Compact design to fit in the most demanding space.

◆ Smooth operation

◆ Low electrical noise

◆ Quick shipment according to your urgent requirement

◆ 360° continuous rotation

◆ High bandwidth data transmission capability
