Description:

LPPL rotating unions can perform 360 degree rotation. The medium includes inert gas such as compressed air, steam, vacuum, nitrogen, hydrogen, etc.
air, steam, steam, vacuum, nitrogen, hydrogen, etc. It can integrate slip ring to transmit various control signals. The sealing
surface and sealing ring are made of special materials with advantages such as wear resistance, durability, corrosion resistance and no leakage.
wear resistance, long life, corrosion resistance and leakage-free. Customers can install LPP rotating unions independently according to the operating conditions.

Features
◎Compressible media: compressed air, nitrogen and other inert gases;
◎Small size, light weight, low torque
◎Built-in power supply, switching signal, Ethernet, USB, fieldbus, sensor and other signals;
◎The parameters of rotating joint and built-in slip ring can be customized according to customer’s requirements;
◎Joint parameters and pipe diameter can be customized according to customer’s requirements;

Optional
◎ Inner diameter and outer diameter/Number of circuits/Current and voltage/Wire length/Case material and
Color/Protection Level/Signal and power can be transmitted separately or in combination

Applications:
◎Industrial automation
◎Packaging equipment
◎SMT equipment
◎Testing equipment
◎Robots
