Slip rings for electronic total station detector
An electronic total station is an optical surveying instrument used to calculate angles and distances. An electronic total station is a versatile electronic device consisting of an electric theodolite, an electronic transistor and a processor. This device is widely used in land surveys. In such a device, the slip ring is an indispensable component. The […]
Information
An electronic total station is an optical surveying instrument used to calculate angles and distances. An electronic total station is a versatile electronic device consisting of an electric theodolite, an electronic transistor and a processor. This device is widely used in land surveys. In such a device, the slip ring is an indispensable component. The electrical rotary connections allow the sensors and optical components to rotate 360 degrees unrestrictedly. Meanwhile, the slip ring enables the transfer of power and signals between the sensors and the processor.
As an expert in slip rings, JINPAT Electronics offers customers a variety of slip ring solutions. And of course, JINPAT has slip ring models designed for electronic total stations. For precision equipment and devices such as electronic total stations, JINPAT’s slip rings for capsules, miniature slip rings, and super miniature slip rings are optional. However, to name the most suitable type of slip ring, JINPAT PCB pancake type slip ring is undoubtedly the best choice.
Considering the limited installation space in the electronic total station, the JINPAT PCB flat contact ring can easily fit into it and also the PCB can be folded according to the layout of the application. With its compact size and innovative PCB design, the JINPAT PCB flat contact ring is characterized by its flexibility. Meanwhile, JINPAT flat slip ring PCB will also surprise customers with its high electrical performance and ultra-long service life.
Features and advantages
◆ Transmission with 360° rotation without coiling wires
◆ Transmission of various types of signals including Ethernet, USB, RS, CANBUS, FireWire, servo, encoder, load cell, thermocouple, HDMI
◆ Ability to integrate into blocks with excellent conductivity
◆ Reliable operation, no signal interference, no data packet
◆ High speed operation
◆ Low electrical noise (min. 1 mOhm)
Adaptable to a wide temperature range from -60 ℃ ~ + 120 ℃
◆ High level of protection up to IP68
◆ No maintenance required
◆ Long service life
◆ Mass production, fast delivery
◆ Competitive cost
