Contact ring for USB 2.0 signal transmission

The USB interface was developed to standardise the connection of peripheral devices to personal computers. It has largely replaced interfaces such as serial and parallel ports, and has become commonplace for connecting many types of devices such as personal computers and peripherals. USB interface is gradually penetrating into fields such as machine vision, data acquisition, photographic equipment, digital television, entertainment equipment, etc.

USB slip rings manufactured by JINPATElectronics are specially designed for USB signal transmission. These slip rings are characterised by sufficient number of channels for signal transmission and stable signal transmission. This series includes both USB 2.0 slip rings and USB3.0 slip rings. JINPATElectronics’ USB signal transfer slip rings are the optimal solution for high-speed transmission of large amounts of data between electrical components.

Advantages of USB signal transmission slip rings manufactured by JINPATElectronics:
High data transfer rate. For USB 3.0, the theoretical data transfer rate is 5.0 Gbit/s, measured data transfer rate > 2.0 Gbit/s.
Electrical and electro-optical transmission possible.
Possibility to integrate multiple signal transmission channels. Maximum number of channels: 2USB3.0 channels and 12 USB2.0 channels.
Best contact materials guarantee low electrical noise and super long service life.
Different types of connectors for the ability to choose the right one.
