LPFO optical slip rings are also known as fiber optic rotary couplings, optical rotary couplers. Optical contact ring aOptical LPFO contact rings are also known as fiber optic rotary couplers, optical rotary couplers. Optical slip ring uses optical fiber as a carrier. It offers the best solution for high capacity data and signal transmission. Optical slip ring can be integrated with traditional electrical slip rings. The hybrid slip ring model is capable of transmitting power, signals and high-speed data.

Advantages：
◎ No contact and friction, long service life, up to 10 million rpm (more than 100 million rpm for signal channel)
◎Can be combined with multiple signals, such as video, series, Ethernet signal, etc.
◎Utilizes optical fiber to transmit information, no leakage, no electromagnetic interference; can transmit tens of hundreds of
kilometers of network applications over long distances.
◎The transmission capacity is much larger than that of an electrical connector, and can be used to double the bandwidth
using a wavelength-division multiplexer.
◎Small volume and light weight, which is easy to integrate with the electrical slip ring, and the system is easy to upgrade and change
◎We offer the world’s smallest single-channel fiber optic rotary joints, as well as two-channel, four-channel,
ten-channel, and even more channels of your choice.
◎Providing photovoltaic integrated rotary joints

Options：
◎Fiber optic transmission type is optional, current and signal circuits are optional.
◎Single-mode or multi-mode, single-channel or multi-channel
◎Shape can be customized, housing material and drive connector are also optional.
