Description：

LPFO optical slip rings are also known as fiber optic rotary couplers, optical rotary couplers. Optical contact ring uses optical fiber as a carrier. It offers the best solution for large data and signal transmission Fiber optic slip rings LPFO, also known as fiber optic rotary couplers and fiber optic rotary connectors, with fiber optic as the transmission medium, provide the best solution for resolving large amounts of data and signals between rotating connected system components.

Advantages：
◎ No contact and friction, long service life, up to 10 million rpm (more than 100 million rpm for signal channel)
◎Can be combined with multiple signals, such as video, series, Ethernet signal, etc.
◎Utilizes optical fiber to transmit information, no leakage, no electromagnetic interference; can transmit tens of hundreds of
kilometers of network applications over long distances.
◎The transmission capacity is much larger than that of an electrical connector, and can be used to double the bandwidth
using a wavelength-division multiplexer.
◎Small volume and light weight, which is easy to integrate with the electrical slip ring, and the system is easy to upgrade and change
◎We offer the world’s smallest single-channel fiber optic rotary joints, as well as two-channel, four-channel,
ten-channel, and even more channels of your choice.
◎Providing photovoltaic integrated rotary joints

Options：
◎Fiber optic transmission type is optional, current and signal circuits are optional.
◎Single-mode or multi-mode, single-channel or multi-channel
◎Shape can be customized, housing material and drive connector are also optional.

Typical application：
◎ Robotics
◎ Material handling system
◎ Rotating turret on a vehicle
◎ Remote control system
◎ Radar system
◎Marine and offshore system
◎High-speed video, digital, analog signal transmission and control of fiber optic sensor turntable
◎Medical system
◎Camera surveillance system
◎National or international security systems
◎Underwater operating systems
